A closer look at the tools
behind the testing.
Rotate the equipment, explore its parts and follow what happens beneath the surface. Choose a study to begin.
Explore the Dynamic Cone Penetrometer. Rotate the instrument, separate its components and follow the testing cycle.
DRAG TO ROTATEUSE THE VIEW CONTROLS
GROUND INTELLIGENCE / UP CLOSE
Get to know
the equipment.
A closer look at the tools behind the testing.
Explore a Dynamic Cone Penetrometer in 3D.
DYNAMIC CONE
PENETROMETER
Built for the ground.
Drag to turn the equipment. Look closely at the guide rod, drop hammer and anvil that turn each impact into useful ground information.
- 01 / DROP HAMMER
- A guided weight delivers the impact.
- 02 / ANVIL & GUIDE
- Keeps the moving parts aligned.
- 03 / ROD & CONE
- Transfers each blow into the soil.
Illustrative model based on equipment references. Movement and proportions are explanatory; this is not a measured scan or a test result.
Illustrative equipment studies. Movement, proportions and measurement paths are simplified for explanation; these models do not display live test results.
